ATLANTIS Aquahelm

LIGHT AND VERSATILE TENDER WITH REMOTE STEERING


A300Q

9’10” long, 20HP max


A330Q

10’10” long, 30HP max


A360Q

11’10” long, 30HP max


A390Q

12’10” long, 30HP max

The AQUAHELM for GALA boats is THE IDEAL SOLUTION if you are looking for the lightest tender with remote steering. Four GALA models can be equipped with the AQUAHELM S-08 steering console & seat combo. It is an innovative design from GALA.



Extremely light and versatile with slim, eye-catching outlines, it easily converts your dinghy to an unbeatable center console! Available as an upgrade for models A300D, A330D, A360D, A390D. The console can be installed any time if you want to upgrade from classic tiller drive to remote control steering. You can also adjust console and arm positions for your comfort.

  • STANDARD FEATURES
    Medium-V, powder-coated aluminum hull with antiskid decking and hidden reinforced transom brackets ENVIROX chromate-free titanium hull protection «GALA TABS» – special patented GALA hull design with transom extensions Spacious bow locker with access hatch SILVERTEX bow locker cushion Two aluminum seats (one on A240D) with sliding installation system Substantial keel protector 4 lifting eyes and 3 towing bow eyes Bow handle and two rear handles GALA bow cleat and 8/10 grab handles Soft curved 3-chamber PVC or Hypalon buoyancy tube with rounded bow and original «GALA-JET» design Overpressure valve Tough rubbing strake with splash guard One-way drain valve with pull-up handle Two oars with oarlocks and oar stops High-efficiency foot pump Repair kit and manual
  • OPTIONAL EQUIPMENT
    Bow step plate with back cushion Overall cover Aluminum sliding seat extra Removable soft seat cushion Under-seat bag SEADECK double layer upgrade Diamon stitch upholstery upgrade Tube protector upgrade Transom launching wheels installation brackets Removable fishing panel with 2 rod holders
  • A240D SPECIFICATION
    Length: 240 cm / 7’10” Length inside: 170 cm / 5’7″ Width overall: 170 cm / 5’7″ Width inside: 82 cm / 2’8″ Tube Diameter: 44 cm / 17″ Bare boat weight: 54 kg / 118 lbs Loading capacity: 350 kg / 770 lbs Passenger capacity: 3 Number of chambers: 3 Engine recommended: 5 HP Engine MAX: 6 HP Engine weight MAX: 35 kg / 77 lbs Engine shaft length: 15″ (short) Aluminum hull thickness: 2.5 mm / 7/64″ Boat design category: D All technical data are subject to change without notice. The products details and specifications may be changed from specified herein. All the dimensions are + or – 3%. All the weights are + or – 10%
  • A270D SPECIFICATION
    Length: 270 cm / 8’10” Length inside: 192 cm / 6’4″ Width overall: 170 cm / 5’7″ Width inside: 82 cm / 2’8″ Tube Diameter: 44 cm / 17″ Bare boat weight: 59 kg / 130 lbs Loading capacity: 450 kg / 990 lbs Passenger capacity: 4 Number of chambers: 3 Engine recommended: 8 HP Engine MAX: 10 HP Engine weight MAX: 45 kg / 99 lbs Engine shaft length: 15″ (short) Aluminum hull thickness: 2.5 mm / 7/64″ Boat design category: D All technical data are subject to change without notice. The products details and specifications may be changed from specified herein. All the dimensions are + or – 3%. All the weights are + or – 10%
  • A300D SPECIFICATION
    Length: 300 cm / 9’10” Length inside: 222 cm / 7’3″ Width overall: 170 cm / 5’7″ Width inside: 82 cm / 2’8″ Tube Diameter: 44 cm / 17″ Bare boat weight: 64 kg / 140 lbs Loading capacity: 500 kg / 1100 lbs Passenger capacity: 5 Number of chambers: 3 Engine recommended: 10 HP Engine MAX: 15 HP Engine weight MAX: 50 kg / 110 lbs Engine shaft length: 15″ (short) Aluminum hull thickness: 2.5 mm / 7/64″ Boat design category: C All technical data are subject to change without notice. The products details and specifications may be changed from specified herein. All the dimensions are + or – 3%. All the weights are + or – 10%
  • A330D SPECIFICATION
    Length: 330 cm / 10’10” Length inside: 252 cm / 8’3″ Width overall: 170 cm / 5’7″ Width inside: 82 cm / 2’8″ Tube Diameter: 44 cm / 17″ Bare boat weight: 69 kg / 152 lbs Loading capacity: 550 kg / 1210 lbs Passenger capacity: 5 Number of chambers: 3 Engine recommended: 15 HP Engine MAX: 20 HP Engine weight MAX: 60 kg / 132 lbs Engine shaft length: 15″ (short) Aluminum hull thickness: 2.5 mm / 7/64″ Boat design category: C All technical data are subject to change without notice. The products details and specifications may be changed from specified herein. All the dimensions are + or – 3%. All the weights are + or – 10%
  • A360D SPECIFICATION
    Length: 360 cm / 11’10” Length inside: 282 cm / 9’3″ Width overall: 170 cm / 5’7″ Width inside: 82 cm / 2’8″ Tube Diameter: 44 cm / 17″ Bare boat weight: 74 kg / 162 lbs Loading capacity: 600 kg / 1320 lbs Passenger capacity: 6 Number of chambers: 3 Engine recommended: 20 HP Engine MAX: 25 HP Engine weight MAX: 70 kg / 154 lbs Engine shaft length: 15″ (short) Aluminum hull thickness: 2.5 mm / 7/64″ Boat design category: C All technical data are subject to change without notice. The products details and specifications may be changed from specified herein. All the dimensions are + or – 3%. All the weights are + or – 10%
  • A390D SPECIFICATION
    Length: 390 cm / 12’10” Length inside: 312 cm / 10’3″ Width overall: 170 cm / 5’7″ Width inside: 82 cm / 2’8″ Tube Diameter: 44 cm / 17″ Bare boat weight: 80 kg / 174 lbs Loading capacity: 650 kg / 1430 lbs Passenger capacity: 6 Number of chambers: 3 Engine recommended: 25 HP Engine MAX: 30 HP Engine weight MAX: 70 kg / 154 lbs Engine shaft length: 15″ (short) Aluminum hull thickness: 3 mm / 1/8″ Boat design category: C All technical data are subject to change without notice. The products details and specifications may be changed from specified herein. All the dimensions are + or – 3%. All the weights are + or – 10%
  • TUBE AND DECOR COLOURS
    LIGHT GRAY / GRAY: Light gray tube with gray decor. White hull (Default color). WHITE / GRAY: White tube with gray decor. White hull. BLACK / GRAY: Black tube with gray decor. Dark gray hull. CUSTOM: Some other colors for tube, tube decor and hull can be available on request. Ask us for availability.

"GALA TABS"
hull design

GALA Tabs are a patented feature created by GALA. They significantly improve performance and make getting on plane easier than ever before!

CONSOLE SLIM DESIGN

AQUAHELM console has an elegant and slick design with enough interior room for a lot of equipment

LOTS OF LEG ROOM

The AQUAHELM concept provides an exceptionally spacious cockpit, especially LEG ROOM for the driver and passengers.

extremely low
weight

Each GALA Atlantis-AQUAHELM is extremely lightweight, making it an unbeatable choice when you need something light with remote steering!

overpressure
valve

Each boat is equipped with the advanced Overpressure Valve for protection against overheating and over-inflating.

find your perfect gala boat

Discover our latest range of new and approved used GALA RIBs and inflatable boats. Whether you're seeking innovative design, exceptional performance, or a trusted pre-owned model, we have the perfect GALA boat for you. Start your adventure with GALA today!
